RUUD #57 332K BTU Liquid Propane Digital Pool Heater

The Ruud P-D336A Liquid Propane Digital Polymer Pool/Spa Heater meets or exceeds all federal and state standards with Ruud’s energy-smart heaters consistently achieve the highest efficiency ratings. The ProTek Shield is a cutting-edge module that protects the heat exchanger and extends the life of your Digital Gas Pool and Spa Heater. Rest, soak or swim knowing that your pool heater investment can be enjoyed even longer thanks to this innovative, patent-pending technology.

Specifications

• ItemShipping Dimensions: 44 x 31 x 30 inch
• Cabinet Depth: 28 inch
• Cabinet Height: 38 inch
• Cabinet Width: 26 inch
• Channel: Pool Equipment
• Commercial, Residential, or Professional: Commercial, Residential
• Control Type: Digital Electronic
• Each Product Weight: 224 pound
• Flow Rate Max: 125 gal/min
• Flow Rate Min: 125 gal/min
• Frequency Rating (Hz): 60
• Fuel Type: Propane
• Green or Energy Efficient Product: True
• Phase: Single
• Standards Approvals: ASME Certified
• Voltage: 115V, 230V
• BTU Input: 332500 British thermal unit
• Burner Orifice Size: #57
• Elevation Max: 2000 foot
• Elevation Min: 0 foot
• Flue Diameter: 8 inch
• Gas Connection: 0.75 inch
• Gas Connection FIT: NPT
• Header Material: Polymer
• Indoor Drafthood: 63 inch
• Minimum J: 10.625 inch
• Stackless Outdoor Top: 40 inch

What’s in the Box

1 x Ruud Raypak #57 Liquid Propane Digital Heater 332K BTU
1 x User Manual
