Renogy Suntree 50A 1P Miniature Circuit Breaker

The Renogy Suntree 50A 1P Miniature Circuit Breaker is your go-to solution for circuit protection and safety. Designed with precision and efficiency in mind, this miniature circuit breaker is perfect for safeguarding your electrical system against overloads and short circuits.

Compact in size yet powerful in performance, the Renogy Suntree 50A 1P Miniature Circuit Breaker can handle up to 50 amps of current easily. Its single-pole design makes it versatile and easy to install in a variety of applications, from residential to commercial settings. Multiple safety certifications and a strong 1.5-year warranty on material and workmanship make it a reliable and dependable device protector.

Don’t compromise on quality when protecting your valuable electronics – choose the Renogy Suntree 50A 1P Miniature Circuit Breaker for peace of mind and confidence in your electrical system!

Highlights

•    Double security
•    Safe to use
•    Durable
•    Built-in indicator window
•    Easy installation
•    Multiple safety certifications

SPECIFICATIONS:

Rated Insulation Voltage: 1250V

Operating Temperature Range: -22℉~158℉ (-30℃~70℃)

Storage Temperature Range: -40℉~185℉ (-40℃~85℃)

Rated Operating Voltage: 250V

Rated Frame Current: 63A

Protection Rating: IP20

Rated Current: 50A

Operating Relative Humidity: ≤95%

Number of Poles: 1

Rated Non-Tripping Current: 10.5A/16.8A/33.6A/52.5A/66.15A (≥1h)

Rated Tripping Current: 13A/20.8A/41.6A/65A/81.9A (<1h)

Rated Instantaneous Tripping Current: 60A/96A/192A/300A/378A (<0.1s)

Operating Short-Circuit Breaking Capacity: 6KA

Ultimate Short-Circuit Breaking Capacity: 6KA

Rated Impulse Withstand Voltage: 6KV

Certifications: CE, RoHS, CB, TUV, SAA

Mechanical Life: 20000 Times

Electrical Life: 1000 Times (<125VDC)

Trip Mechanism: Thermal-Magnetic

Damp Heat Resistance: Type 2

Dimensions: 3.2 x 3.0 x 0.7 in (82 x 76 x 18 mm)

Weight: 4.2 oz (120 g)

Installation Method:  DIN Rail

Recommended Terminal Torque: 17.7 inch·lbs~20.4-inch lbs (2 N·m~2.3 N·m)

Conductor Size: 14 AWG~4 AWG

Material and Workmanship Warranty: 1.5 Year

WHAT’S IN THE BOX:

1 x Renogy 50A 1P Miniature Circuit Breaker
