Hayward ProSeries™ 21″ Sand Filter w/ 1.5 HP PowerFlo Matrix® Pump

High performance filter from the Hayward Pro Series W3S210T93S combine exceptional flow characteristics, features, and ease of use for usage in a variety of applications. Installation is made simple by the flange clamp’s 360° rotational capability. To make the most of the filtration area, an integral top diffuser makes sure that water is distributed evenly across the entire sand bed. Umbrella-fold self-cleaning laterals with precise engineering for balanced flow, backwashing, and serviceability.

• Durable filter tank for long-lasting, all-weather performance
• Large pressure sand/water drain for rapid winterizing or servicing
• 7-position VariFlo valve provides maximum flow at lower pressure drops
• Integral sight glass lets you see when the backwash cycle is completed
• Rapid Winterizing
• Maximum Filtration

SPECIFICATIONS:

Brand: Hayward

Manufacturer Part Number: W3S210T93S

Series: ProSeries

Diameter: 21”

Effective Filtration Area: 2.2 Sq Ft

Sand Required: 200 lb.

Flow Rate: 44 gpm

8 hour Turnover (in Gallons) – 21,120

Filter Type: High-rate sand: No. 20 silica sand (0.45 mm – 0.55 mm)

Filter Tank: Molded polymeric

Underdrain: 360° self-cleaning slotted laterals, precision installed in ball-joint assembly

Control Valve: Seven-position, top-mount VariFlo valve with lever-action handle

Valve Fastening: Flange clamp design

Pump and Motor: PowerFlo LX or PowerFlo Matrix Series Pump – 115 volts

Mounting Base: Injection-molded thermoplastic

Warranty: 1 Year Limited

WHAT’S IN THE BOX:

1 x Hayward ProSeries® 21″ Side-Mount w/ Valve W3S210T93S

1 x 21” Polymeric Tank

1 x 1.5 HP PowerFlo Matrix Pool Pump

1 x One-piece Deluxe Base

1 x 1 1⁄2″ Hose Package
