Carbon Side Plate for Teradek / KEYSTONE / KOMODO-X
$36.00 – $100.80
Carbon Side Plate for Teradek / KEYSTONE / KOMODO-X
This ultra slimline Carbon Side Plate enables these Teradek transmitters:
- Gen 4: Teradek Bolt LT/XT 500, 1000, 3000
- Gen 5: Teradek Bolt 4K LT 750, 1500, MAX
- Gen 6: Teradek Bolt 6 LT 750, 1500, MAX
…to mount to these KEYSTONES:
———————————————
Rigging this way positions the TX in the optimal position — minimising impact on buttons, airflow and threads.
SDI ports are close together so cables are short in length — eliminating coiling and snags.
The aim is keep the TX mounted to the camera at all times! Whether you’re on gimbal, handheld or tripod. Less bulk, no ball heads unexpectedly dropping, saving valuable time on set 🔥
We recommend using the following power cables for your TX to truly achieve a fast and clutter free Ignite LIT RIG! 🔥✨
———————-
Gen 4: Teradek Bolt LT/XT 500, 1000, 3000
- Use a 2-Pin Lemo Right Angle to 2-Pin Lemo Straight / 5-inch when sourcing power from our Power Breakout.
———————-
Gen 5: Teradek Bolt 4K LT 750, 1500, MAX
- Use a 2-Pin Lemo Right Angle to 2-Pin Lemo Straight / 8-inch when sourcing power from our Power Breakout.
———————-
Gen 6: Teradek Bolt 6 LT 750, 1500, MAX
- Use a 2-Pin Lemo Right Angle to 2-Pin Lemo Straight / 8-inch when sourcing power from our Power Breakout.
———————-
The following screws are included with the Carbon Side Plate. And we throw in some spares!
————————
Use four M2 x 6mm socket head cap screws to mount a Gen 4: Teradek Bolt 500, 1000 & 3000 XT / LT.
Use two ¼”-20 x ½” countersunk screws to mount a Gen 5: Teradek Bolt 4K LT 750, 1500 & MAX.
Use two ¼”-20 x ½” countersunk screws to mount a Gen 6: Teradek Bolt 6 LT 750, 1500 & MAX.
Use three M4 x 8mm countersunk screws to mount the Carbon Side Plate to KEYSTONE.
- SHIPS WITH
Six M4 x 8mm countersunk screws
Eight M2 x 6mm socket head cap screws
Three ¼”-20 x ½” countersunk screws
WEIGHT
0.00oz / 00g with M4 screws
DIMENSIONS
3.55 x 3.77 x 0.11” / 90.3 x 96 x 3mm You may also like our other carbon plates:
