Acopower 25W Off-grid Solar Kits, 5A charge controller with SAE connector

A comprehensive solar kit from Acopower, the 25W off-grid Solar Kit and 5A charge controller with SAE connector is what you need to kick start your dream to tap into the greenest energy source, the solar power.

Engineered for off-grid applications like water pumping systems, signaling systems and every fancy of your outdoor adventure, our 25W poly solar panels are designed for high module conversion efficiency. Perfected for your RVs, boats, cabins and cars, the kit charges 12V lead acid batteries including sealed, flooded, GEL and AGM.

The 5A charge controller has been upgraded to positive grounding, giving you a chance to expanse your solar system for broader applications. A safety regulator is in place to cut-off charging when the battery is fully powered and resume charging when voltage drops.

Acopower’s 25W solar panels are highly durable and built to withstand high wind (2400Pa), snow loads (5400Pa) with an anti-reflection coated glass of 3.2 mm and IP65 waterproofing.

Specifications:

Peak Power (Pmax):25W

Peak Circuit Voltage(Voc):22V

Max Power Voltage(Vmp):17.5V

Short Circuit Current(Isc):1.54A

Max Power Current(Imp):1.43A

Maximum System Voltage DC:1000V

Application Class:Class A

Charge Controller: 5A PWM (Positive Grounded)

Working Voltage :12V

Working Current:5A

Working Mode: PWM Charging Add a +5V/1.2A USB Terminal Output

Battery Type Options: Sealed, Gel, Flooded

What’s in the Box:

1 x 25W Solar Panel

1 x Solar Charging Controller with SAE adapter and Alligator Clips

1 x User Manual
