Acopower 100W monoRV SystemGel Battery 400ah3kw 400w

Introducing the Acopower 100W mono RV System Gel Battery 400ah3kw 400w – the ultimate power solution for your recreational vehicle!

Designed to provide you with reliable and efficient power no matter where your adventures take you, the 100W mono RV solar panels boast superior efficiency, allowing you to harness maximum solar energy and convert it into usable power. With its mono-crystalline technology, these panels guarantee exceptional performance, even in low-light conditions.

Paired with the 400ah3kw gel battery, you can store an incredible amount of power to keep your RV running smoothly. The gel battery is known for its exceptional deep-cycle performance, making it ideal for long trips or off-grid living. Equipped with a 400W inverter, this system allows you to convert DC power to AC power effortlessly so that you can power up your appliances, charge your devices, and enjoy all the comforts of home on the road.

The Acopower 100W mono RV System Gel Battery 400ah3kw 400w is built to last, featuring sturdy construction and high-quality materials to withstand the harshest conditions. Its compact and lightweight design ensures easy installation, while the comprehensive user manual provides step-by-step guidance for a hassle-free setup.

Experience the freedom and convenience of sustainable and clean energy with the Acopower 100W mono RV System Gel Battery 400ah3kw 400w!

• Clean, reliable power for your boat, RV
• Efficient outdoor solar panels
• 400-Watt RV monocrystalline solar power kit
• 40-amp MPPT charge controller
• Large, four-panel solar system
• Perfect for van lifers, campers, boaters, and RV dwellers
• 100 Ah deep-cycle battery
• 12-volt DC to 120-volt AC pure-sine wave inverter
• Inverter has an overload protection of 1,800 watts
• Peak efficiency of 99.5%.
• Kit comes with all the necessary mounting hardware and connector wires
• Easy installation

SPECIFICATIONS:

100W Monocrystalline Solar Panel

SKU: HY-400AH3KW-400WMB

Maximum Power at STC (Pmax): 100W

Open-Circuit Voltage (Voc): 22V

Maximum Operating Voltage (Vmp): 17.48V

Short-Circuit Current (Isc): 6.14A

Maximum Operating Current (Imp): 5.71A

Operating Temperature: -40ºC to 85ºC

Dimension: 1130x510x35mm / 44.5×20.1×1.4 in

Weight: 5.8 kg / 12.8 lbs

3000W Inverter 12VDC to 120VAC

Related power: 3000W

Overload Protection: 1800W±100W

Peak Power: 6000W

Over Temperature Protection: 105±5℃

Input Voltage: DC12V（11-14V)

Over Temperature Protection recover: ≤65℃

Output voltage: AC110V± 10%

Output short circuit protection: Have

Output frequency: 50HZ ± 2HZ

Remote Control Function Optional

Output waveform: Pure Sine Wave Mounting bracket Optional

THD: ≤3%

Conversion efficiency: ≥90%

Input quiescent current： ≤0.6A

USB output: 5V 2400mA Auto (MAX)

USB overcurrent protection: ≤3.5A

Cooling way: Temperature-control Fan

Display model: LED+LCD

Under Voltage protection: 10.0V ± 0.5V

Overvoltage protection: 15.5V±0.5V

Shell Material: ABS + PC + Aluminium Alloy

Dimension: 242 × 463 × 118 mm

Weight: 5.5kg

12V 200 Ah Rechargeable Deep Cycle GEL Battery

Nominal Voltage: 12V

Rated capacity (10 hour rate): 200Ah

Terminal type: T16A

Internal resistance (Fully charged, 25℃): Approx.3.3m Ω

Nominal operating temperature: 25℃±3℃(77℉±5℉)

Maximum charging current: 40A

Dimension: 20.55×9.37×8.58 in

Weight: 62.5kg (137.8lbs)±3%

MPPT 40A Charge Controller

Nominal System Voltage: 12/24VDC Auto

Grounding: Common negative

Rated Charge Current: 40A

Battery Input Voltage Range: 8V～32V

Max. PV Open Circuit Voltage: 100V (1) 92V (2)

Rated charge Power: 520W/12V 1040W/24V

MPPT Voltage Range: (Battery Voltage+2V) ~72V

RS485 Interface: 5VDC/200mA (RJ45)

Working temperature: -25℃～+50℃

Storage temperature: -20℃～+70℃

Terminals: Up to 6 AWG

Enclosure: IP33

Dimension: 10×7.28×2.67 in / 255×185×67.8mm

Weight: 3.75lbs / 1.7kg

WHAT’S IN THE BOX:

4 x 100W Mono Solar Panel

1 x 3000W Inverter

2 x 200Ah Gel Battery

1 x 40A MPPT Charge Controller

1 x 50A Fuse

1 x Battery Switch

4 Sets x Mounting Z Bracket

1 Pair x 30ft 12AWG PV Cable

2 Pairs x 1Ft 2AWG Battery Cable

1 Pair x 8FT 8AWG Tray Cable

1 x Cable Entry Housing

1 Pair x Y Branch Solar Panel Connectors
